    High Efficiency Ss304 Sand Drying Machine Large Electric Sludge Slurry Rotary

    Ask Lasest Price
    Brand Name : Xin Shengman
    Model Number : Hollow blade Drying machine
    Certification : ISO9001 and CE
    Price : USD1,5000-USD20,3000
    Payment Terms : T/T
    Supply Ability : 6sets/Month
    Delivery Time : 30-60 days
    • Product Details
    • Company Profile

    High Efficiency Ss304 Sand Drying Machine Large Electric Sludge Slurry Rotary


    High efficiency large electric sludge slurry rotary sand drying machine


    Product details


    Our company's dryer is a new type small multi-functional dryer, suitable for various drying operations, and four feet can install mobile wheel, which can adapt to a variousworking environment.The main models are 300, 500, 1000, 2000 and 4000, and can accept different models customized according to customer demand, Our compny senior engineer track and guide the whole process , in order to meet customer request!


    Working Principle

    The paddle dryer is compact in structure and mainly consists of a sandwich casing, a central shaft with staggered blades, inlet and outlet joints, drive mechanisms, control boxes, and other components.


    The cylinder is a jacket structure in which hot steam circulates inside. During operation, water vapor is introduced into the jacket, hollow shaft, and blade to provide the heat required for drying; a very small amount of air is introduced into the dryer and used as a carrier for the steam (or organic steam) that evaporates during drying; the material enters the machine from the feed port, and is conveyed by the hollow blade to the discharge port for discharging. The material is heated and evaporated by the hollow blade and the jacket during the conveying process to be dried. The heat transfer surface of the wedge blade has a self-cleaning function. The relative motion between the particles and the wedge surface produces a washing effect that washes away the adhering material on the surface of the blade, which allows the material to have a long residence time and a high fill factor.

    High Efficiency Ss304 Sand Drying Machine Large Electric Sludge Slurry Rotary

    High Efficiency Ss304 Sand Drying Machine Large Electric Sludge Slurry Rotary


    Technical parameters


    ModelKJG-2.7KJG-24KJG-52KJG-81KJG-110
    Heat transfer area2.7245281110
    effective volume0.061.533.966.439.46
    revolution15-3010-2010-205-155-10
    power2.211305595
    width of dryer body3061118147418282210
    total width7361474185422862668
    length of dryer body19563454525860206122
    total length29726147830696789880
    distance between feeding and disharging17523150495455625664
    height in center380106612201220
    total height762203224642668
    steam inlet(2) 3/4(2) 1(2) 11/2(2) 11/2(2) 2
    water outlet(2) 3/4(2) 1(2) 11/2(2) 11/2(2) 2

    High Efficiency Ss304 Sand Drying Machine Large Electric Sludge Slurry Rotary


    Applications


    Petrochemical industry: polyolefin powder, polycarbonate resin, high and low-density polyethylene, linear low-density polyethylene, polyacetal granules, nylon 6, nylon 66, nylon 12, acetate, polyphenylene sulfide, propylene base resin, polypropylene, engineering plastics, polyvinyl chloride, polyvinyl alcohol, polystyrene, polyester, polyoxymethylene, styrene-acrylonitrile copolymerization, ethylene-propylene copolymerization.


    Environmental protection industry: sludge, electroplating sewage sludge, boiler soot, sugar factory waste residue, pharmaceutical factory waste residue, MSG factory waste residue, coal ash.


    Feed industry: soy sauce residue, bone-based feed, distiller's grains, food scraps, apple pomace, orange peel, soybean meal, chicken bone feed, fish meal, feed additives, bio-sludge.


    Food industry: starch, cocoa beans, corn kernels, salt, modified starch, medicines.


    Chemical industry: soda ash, NPK compound fertilizer, kaolin, bentonite, white carbon black, carbon black, phosphogypsum, calcium sulfate, calcium nitrate, magnesium carbonate, sodium cyanide, oxidized sodium fluoride, aluminum hydroxide, barium sulfate, calcium carbonate, molecular sieves, dyes, saponins.


    High Efficiency Ss304 Sand Drying Machine Large Electric Sludge Slurry Rotary

    Paddle dryer has following main features:

    1.Compact structure, large efficient heat transfer area, and small occupied

    area.

    2.Stirring is uniform, heat efficiency is high, and drying efficiency is good.

    3.Paddle shafts can mesh each other, and have self-clean function, it can

    avoid material stick on the wall.

    4.Energy consumption is low, and operating cost is low

    5.Little dust carried out, little material loss

    6.Heat indirectly, material can not be polluted

    7.Rotary speed of paddle shaft is low, it will not destroy the shape and

    property of product

    8.Operating flexibility is large, running is stable and reliable.
