High quality button control LDH Series Coulter Mixer for chemical industry
Introduction
This machine is composed of transmission device,horizontal cylinder, coulter, and fly cutter. The raw material flows circumferentially along the cylinder and it will be tossed and sprinkled under action of the high speed rotating cutler. Therefore, the material can be evenly mixed in a shorter time.
Detailed Information
1. Volume: 500-20000L
2. Contact Material: SS304, SS316L
3. Usage: Pharmaceuticals, pesticides, pigment, paint, dyestuff, building material, refractory material, foodstuff, food additives, milk powder, compound fertilizer, fodder, plastic, cosmetics etc.
4. Product type: Mixer
5. Function: Mixing
6. Mixing type: Colter/plow
7. Color: Customized
8. Motor power: Customized
9. Volt: 220V, 380V, or customized
10. Discharge mode: Pneumatic large door structure, manual butterfly valve or pneumatic butterfly valve
11. Condition: New
12. Dimension: Customized
13. Weight: Customized
14. Certificate: CE ISO
15. Warranty: 1 year
16. After-sales servie: Video technical support, online support.
Technical Parameters
| Type | one time mixing(kg) | Power(KW) | Weight(kg) |
| LDH-0.1 | 40-60 | 3.7 | 430 |
| LDH-0.3 | 120-180 | 7.7 | 950 |
| LDH-0.5 | 200-300 | 8.5 | 1100 |
| LDH-1 | 400-600 | 15.5 | 1800 |
| LDH-2 | 800-1200 | 23 | 2520 |
| LDH-4 | 1600-2400 | 28 | 3220 |
| LDH-6 | 2400-3600 | 33 | 6750 |
| LDH-8 | 3200-4800 | 37 | 7200 |
| LDH-10 | 4000-6000 | 41 | 7500 |
| LDH-12 | 4000-6000 | 41 | 7500 |
| LDH-10 | 4800-7200 | 48 | 8500 |
| LDH-15 | 6000-9000 | 56 | 9200 |
Note: because the raw material exist in difference, the output in the table is for reference only
Technical advantages
(1) the latest concept of the plough type stirring mechanism of the core technology, plus high-speed rotary cutter head discrete stirring, mixing speed is fast, according to the different formula of the product, the main machine stirring time is 90-180s.
(2) mixing machine mixing precision is high, various materials workability and uniformity is good, do not produce segregation when mixing, mixing ratio can be as high as 1:10,000, to the maximum extent to meet the construction requirements.
(3) unique single door unloading device.No dead zone, no residue, no leakage during unloading, short unloading time.For colored mortar, only simple cleaning or no cleaning is needed when changing the product formula.
(4) with a dynamic artificial sampling mouth, to facilitate the user sampling test, and according to the inspection of the product to adjust the main engine stirring time, to meet the requirements of production.
(5) the cylinder and blade of the main mixing machine adopt imported alloy wear-resistant plate, and the high-speed flying knife adopts wear-resistant alloy casting, which has extremely high wear-resistant performance and prolongs the service life of the main mixing machine.
Applications
This machine is suitable for the mixing of solid-solid (powder and powder), solid-liquid (adding a small amount of liquid into the powder), and some compound technology process such as granulating wet particle and drying. It is especially suitable for mixing viscous material or glue-like additive material.
Pre-service:
As a good and rich experience supplier, we should offer customer
the best quality and best price of the machine.
1. Introduce the suitable product to the customer in detail, answer
the question raised by customer carefully.
2. Make the suitabe project as the customer requirement and make
sure the machine is suitable for the material.
Sale service:
(1). Ensure product with high quality and pre-commissioning before
delivery. (2). Delivery on time. (3). Provide full set of documents as customer’s requirements.
After-sale service:
Provide considerate services to minimize clients’ worries.
1. Assist clients to prepare for the first construction scheme.
2. Install and debug the equipment.
3. Train the first-line operators.
4. Examine the equipment.
5. Take initiative to eliminate the troubles rapidly.
6. Provide technical support.
7. Establish long-term and friendly relationship.
Service commitment:
1. Provide clients one-year warranty to make sure the machine work
well.
2. We always keep certain inventory level of spare parts, which means the replacements can be sent to you timely.
3. Send every client a preferential quotation.
Jiangsu Shengman Drying Equipment Engineering Co.,Ltd, established in 2011, known as a local leading high-tech enterprise, is located in Zhenglu town, Changzhou, Jiangsu, China. Shengman is a large-scale production enterprise in China drying industry with a registered capital of 35,000,000 RMB, specialized in designing &manufacturing various kinds of dryers, granulators, mixers, grinders ,dust removers, etc. Shengman owns an area of over 200,000㎡, and realizes annual sales of over 70,000,000RMB for consecutive years. Shengman has passed European Union CE authentication, ISO 9001 quality management system certification and got good bank credit for AAA. Now Shengman has been one of the largest drying equipment production enterprises in East China and keeping leading the drying industry’s development.
|
|
